Commercial Stainless Steel Worktable Cabinet with Sliding Doors

Sliding-Door Cabinet Specification

Current Sliding-Door Cabinet Reference Configuration

The public product reference combines a preparation top with enclosed storage. Sliding doors are the primary aisle-saving arrangement; lift-up or hinged doors are project options and should not be presented as the same access geometry.

Key Buying Decisions for a Sliding-Door Work Cabinet

Aisle Clearance

Sliding doors do not swing into the aisle, but only part of the cabinet opens at one time. Confirm the usable opening required for stored items.

Internal Shelf Layout

Specify shelf quantity, height and removability. The shelf plan should reflect the sizes and weights of the items stored inside.

Door Alignment and Structure

Cabinet squareness, track installation and floor leveling influence smooth door movement. KD versions require clear assembly and alignment control.

Top Function

Confirm whether the top is used only for preparation or also supports countertop equipment, because reinforcement must match the real load.

Door Opening, Track Access and Cabinet Zoning

A sliding-door cabinet does not provide a full-width opening at one time. Before the cabinet width is fixed, the buyer should identify the largest tray, container or appliance that must pass through the opening. The approved drawing should show the overlap between panels, usable opening on each side, handle profile and whether the doors can be removed for cleaning. This prevents a nominally large cabinet from having an opening that is too narrow for its intended contents.

The internal shelf should be planned as part of the door system, not as an independent line item. A shelf division, centre post or reinforcement placed behind the overlap may restrict access. If the cabinet stores two different groups of items, show their dimensions and preferred access side. The factory can then coordinate shelf length, shelf height and panel travel without assuming that equal cabinet halves are operationally correct.

Worktop, Backsplash and Leveling Decisions

For a cabinet installed against a wall, the rear backsplash height and return should align with neighbouring sinks or tables. For an island or pass-through position, a flat top may be more appropriate. State whether countertop equipment will sit on the worktop and provide its footprint and defined load so reinforcement can be reviewed. Descriptions such as “heavy duty” do not replace an actual use case.

Smooth door movement depends on cabinet squareness and final leveling. The quotation and drawing should identify the base arrangement, adjustable feet or alternative support, and whether the product is shipped welded, modular or knock-down. A KD cabinet must be checked after assembly for diagonal alignment before the door panels are adjusted. The KD sliding-door cabinet assembly guide is the most relevant support page for this structure.

Material and Export Protection for Moving Panels

Material grade, finish and actual thickness should be stated by component: worktop, body panels, internal shelf, doors and any tubular or hardware parts. The door track, panel edges and handles need their own review because repeated movement exposes alignment and finishing issues that are not visible in an overall cabinet dimension. Packing should immobilize the doors, protect exposed corners and keep loose hardware identified by assembly step. A wooden frame or crate is an optional transport decision, not an automatic standard for every order.

Compare Quotations Beyond Overall Cabinet Size

Two sliding-door cabinet quotations can show the same length, depth and stainless steel grade while using different top supports, door-panel construction, tracks, internal shelves and packing. A useful comparison lists actual thickness by component and identifies which features are included. Buyers should also compare the usable door opening, how the doors are removed for cleaning, the internal clear height and whether the cabinet is aligned at the factory or after local KD assembly. These details affect daily access and installation more directly than a generic “commercial grade” description.

For repeat distributor orders, freeze the approved drawing, material schedule, visible finish, hardware and packing method as one model specification. Variations should receive a separate revision instead of being mixed under the same item name.

RFQ Checklist for a Sliding-Door Work Cabinet

• Overall cabinet dimensions and finished working height
• Door opening direction, usable opening width and handle style
• Internal shelf quantity, spacing and expected load
• Backsplash and worktop reinforcement requirements
• Material grade, finish and actual thickness
• Welded or KD preference, quantity, packing and destination

Use the KD sliding-door cabinet assembly guide when the quoted construction is knock-down; use the OEM/ODM process only for non-standard layouts.

Door, Track and Cabinet-Squareness Inspection

A sliding-door cabinet is accepted by usable opening and alignment, not only by external size.

• Level and square the body before checking door travel, overlap and lock engagement.
• Measure the clear opening after handles, tracks and stops are installed.
• Confirm the internal shelf does not obstruct door removal or track cleaning.
• Verify the worktop reinforcement and backsplash independently from the cabinet panels.

Packing Doors and Long Tracks

The current page recommends carton protection with an external wooden frame for this heavier cabinet family, with stronger protection considered for LCL, mixed cargo or higher handling risk. The quotation must state the final method; doors, tracks and hardware should be restrained separately to preserve alignment.

KD Cabinet Alignment and Inspection

For a knock-down cabinet, body squareness, worktop support, internal shelf fit, door-track alignment and fastener access must be controlled together. SENFON can inspect these items against the approved drawing after trial assembly. Actual packed dimensions are recorded for the finished order rather than inferred from a generic KD claim.
